V-Block 20t Electric Industrial Coil Transfer Cart
Introduction
The coil transfer cart is a heavy-duty electric vehicle designed to handle material coils. The structure of the coil transfer cart is similar to that of other common electric transfer carts, but there are V or U shaped brackets mounted on the table of the flat cart. The design of the bracket ensures that the coil is placed safely and stably on the electric cart without the risk of tipping over.
The coil transfer cart is a flexible and customizable piece of equipment that can be customized according to the specific operational needs of different plants. The V/U bracket on the flat cart can be designed in size and number according to the diameter and weight of the coil, making it a universal tool for handling coils of any type of material.
The coil cart saves transportation time and reduces the physical pressure of the material on the transfer cart, thus improving productivity and efficiency.
Heavy Duty Steel Coil Handling Electric Flat Car Battery Powered With E Frame Heavy Duty Steel Coil Handling Electric Flat Car Battery Powered With E Frame
Heavy Duty Steel Coil Handling Electric Flat Car Battery Powered With E Frame Heavy Duty Steel Coil Handling Electric Flat Car Battery Powered With E Frame
Product Details
Parameter List
| Model | KPX-5T | KPX-10T | KPX-20T | KPX-30T | KPX-50T | KPX-100T | KPX-150T |
| Rated load (T) | 5 | 10 | 20 | 30 | 50 | 100 | 150 |
| Table size(mm) | length | 3500 | 3600 | 4000 | 4500 | 5500 | 6500 | 10000 |
| Width | 2000 | 2000 | 2200 | 2200 | 2500 | 2800 | 3000 |
| Height | 500 | 500 | 550 | 600 | 650 | 900 | 1200 |
| Wheel Base (mm) | 2500 | 2600 | 2800 | 3200 | 4200 | 4900 | 7000 |
| Rail Inner Gauge (mm) | 1435 | 1435 | 1435 | 1435 | 1435 | 2000 | 2000 |
| Wheel Diameter(mm) | Φ300 | Φ300 | Φ350 | Φ400 | Φ500 | Φ600 | Φ600 |
| Wheel Quantity(Nos) | 4 | 4 | 4 | 4 | 4 | 4 | 8 |
| Ground Clearance (mm) | 50 | 50 | 50 | 50 | 50 | 75 | 75 |
| Motor Power (Kw) | 1.2 | 1.6 | 2.2 | 3.5 | 5 | 10 | 15 |
| Battery Capacity (Ah) | 180 | 160 | 180 | 250 | 330 | 440 | 600 |
| Battery Voltage (V) | 36 | 48 | 48 | 48 | 48 | 72 | 72 |
| Running speed (m/min) | 0-30 | 0-25 | 0-25 | 0-25 | 0-20 | 0-20 | 0-18 |
| Running Time When Full Load(Hours) | 5.4 | 4.8 | 4 | 3.5 | 3.3 | 3.2 | 3.2 |
| Running Distance for One Charge(Km) | 8.1 | 7.2 | 4.8 | 4.2 | 4 | 3.8 | 3.2 |
| Max Wheel Load (KN) | 25.8 | 42.6 | 77.7 | 110.4 | 174 | 343.8 | 265.2 |
| Reference Weight (t) | 3.6 | 4.2 | 5.9 | 6.8 | 8 | 14.5 | 26.8 |
| Recommended Rail Model | P18 | P18 | P24 | P38 | P43 | QU100 | QU100 |
